Prime Quality Inconel Alloy 600 625 718 Welded Tube And Seamless Pipe Price

Name: Prime Quality Inconel Alloy 600 625 718 Welded Tube And Seamless Pipe Price
Brand: TOBO/TPCO/TISCO/VALIN/METAL
Price: 1 USD

Quality Prime Quality Inconel Alloy 600 625 718 Welded Tube And Seamless Pipe Price for sale

Brand Name : TOBO/TPCO/TISCO/VALIN/METAL

Model Number : 1.4835 Stainless Steel Seamless Pipe

Certification : ISO/PED/TUV/SGS/LR/BV

Place of Origin : China/Japan/Germany

MOQ : 0.5-1 tons

Price : negotiable

Payment Terms : T/T, L/C, Western Union, MoneyGram

Supply Ability : 7500 tons per year

Delivery Time : 15days->

Packaging Details : in plastic bags then in bundles

Standard : DIN, ANSI, ISO, GB, JIS

Sample : Provided,Free,Available free within 7days

Application : Fluid pipe,Structure Pipe

Outer Diameter : 6-813mm

Surface : Annealed & Pickled, Bright Annealing, Polished

Thickness : 0.5-100mm

Material : Carbon Steel,Stainless Steel,alloy steel,Brass,copper

Types : Seamless

Contact Now

Prime Quality Inconel Alloy 600 625 718 Welded Tube and Seamless Pipe Price

Overview

Quick Details

Place of Origin:: China

Type:: Nickel Bar

Application:: widely, in air plane, oil

Grade:: inconel 625

Ni (Min):: 68%

Resistance (μΩ.m):: standard

Powder Or Not:: Not Powder

Ultimate Strength (≥ MPa):: 965

Elongation (≥ %):: 30

Model Number:: inconel 625

Brand Name:: Raymond

Supply Ability

Supply Ability: 10000 Ton/Tons per Month

Packaging & Delivery

Packaging Details: standard export packing or as customer's requirements.

Port: China main port

1.Introduction

Inconel Alloy 625 bar (UNS designation N06625) is a Ni-Cr based superalloy that possesses
 high strength properties and resistance to elevated temperatures. It also demonstrates
 remarkable protection against corrosion and oxidation. Its ability to withstand high stress
 and a wide range of temperatures, both in and out of water, as well as being able to
 resist corrosion while being exposed to highly acidic environments makes it a fitting
 choice for nuclear and marine applications.
 Inconel 625 was developed in the 1960s with the purpose of creating a material that
 could be used for steam-line piping. Some modifications were made to its original
 composition that have enabled it to be even more creep-resistant and weldable.

2.Chemistry

Some chemical properties of Inconel 625 include:

Prime Quality Inconel Alloy 600 625 718 Welded Tube And Seamless Pipe Price

3.ASTM (American Society for Testing and Materials) for various products made
 out of Inconel 625 are as follow:

4.specifications

Specifications and certifications include:
 * AMS: 5599, 5666
 * MS: 5837
 * ASME: SB 443 Gr 1, SB 446 Gr 1
 * ASTM: B 443 Gr 1, B 446 Gr 1
 * EN: 2.4856
 * ISO: 15156-3
 * NACE: MR0175-3
 * UNS: N06625
 * Werkstoff: 2.4856

5.Heat Treatment

Heat Treatment Inconel 625 is usually strengthened by cold work, with annealing at
 temperatures between 1,700 and 1,900F as required to remove the effects of cold work.
 Although nominally a solid-solution alloy containing intergranular and intragranular
 carbide precipitates, Inconel 625 is not responsive to strengthening heat treatments.
 Solution heat treating at 2000 to 2200F dissolves almost all of the secondary carbides.
 The major effects of short-time annealing of hot-rolled bar of standard composition are
 to affect reductions in tensile strength and hardness.Typically, the annealing heat
 treatment most utilized for Inconel 625 is at 1800F.

FAQ

Q: Does this tubing come with triclamp ends to be coupled together?A: This particular tubing comes without tri-clamp ends standard. We can always weld tri-clamp ferrules to the end of tubes for any specific length you need. These products are referred to as tri-clamp spool assemblies. If you need a specific length, please
 contact us.

Q: Are you able to cut tubing to lengths that don't require freight shipping? Say 5' lengths for example.?
A:Yes, we are able to cut down to other sizes. UPS Ground is able to ship up to 7' without the tubing being considered "oversized".We do charge a cutting fee for this service, however. Please contact us for a quote.

Q:How much does 1 stick of 4" tube weigh?
A: One 20' Stick of 4" Sanitary Tubing weighs approximately 75 pounds.

Q:You list gauge of this tubing at 16, but the wall thickness at 0.065". Isn't 16 gauge 0.0625"?
A: The wall thickness and gauges are all displayed in the table below. Please contact us if you have any other questions.

Q: Do you sell tubing in anything less than cases? I need to order just over 400 feet but don't want to pay for two cases as this is More than I need.
 A:  We do sell tubing on an individual basis however there is a $50 "broken box" fee applied to any order less than an entire case.Since we don't offer a way to order individual tube pieces online please call us to place an order over the phone.

Q: Do this product ship via freight?
 A: Yes, our tubing comes in standard 20 foot lengths and will need to ship via freight. I'd also like to mention that there is a broken box charge meaning that if you do not order an entire box of tubing you will be charge additional fees as such. For more information please contact us. Thanks.
