ASTM B622 / Alloy C2000 / UNS N06200 Nickel Alloy Seamless Pipe MT23

Name: ASTM B622 Alloy C2000 UNS N06200 Nickel Alloy Seamless Pipe MT23
Brand: TOBO
Price: 1 USD

Quality ASTM B622 / Alloy C2000 / UNS N06200 Nickel Alloy Seamless Pipe MT23 for sale

Brand Name : TOBO

Model Number : available on request

Certification : Customized logo

Place of Origin : CHINA

MOQ : 1

Price : USD

Payment Terms : L/C, T/T, Western Union

Supply Ability : 1

Delivery Time : 5-8 WORK DAYS

Packaging Details : Wooden box

Application : Petroleum, Chemical, Power, Gas, Metallurgy, Shipbuilding, Construction, etc.

Corrosion Resistance : Excellent

Heat Treatment : Annealing, Quenching, Tempering, etc.

High Temperature Resistance : Excellent

Length : Customized

Material : Nickel Alloy

Shape : Pipe

Size : Customized

Standard : ASTM, ASME, DIN, JIS, ISO, BS, API, EN

Surface Treatment : Polished, Sand Blasting, Anodizing, etc.

Technique : Hot Rolled, Cold Rolled, Cold Drawn, ERW, etc.

Wall Thickness : Customized

Weldability : Excellent

Contact Now

ASTM B622 / Alloy C2000 / UNS N06200 Nickel Alloy Seamless Pipe MT23

Overview

Essential details

Place of Origin:: China

Type:: Nickel Pipe, Seamless

Application:: Industry

Grade:: Nickel Alloy

Ni (Min):: balance

Resistance (μΩ.m):: /

Powder Or Not:: Not Powder

Ultimate Strength (≥ MPa):: /

Elongation (≥ %):: /

Model Number:: MTALI47

Brand Name:: MTSCO

Brand:: MTSCO

Surface finish::: Annealed, polished etc.

Process Method::: Cold Drawn/ Cold Rolled

Quality Assurance:: ISO & PED & AD2000

Inspection:: 100%

Packing:: Plywooden case or Bundle

NDT:: Eddy Current Or Hydraulic Test

Certification:: ISO

Supply Ability

Supply Ability: 500 Ton/Tons per Month

Packaging & delivery

Packaging Details: Bundles for each piece then packed in seaworthy wooden cases for Industrial Pipe

Port: Ningbo

Products Description

ASTM B622 / Alloy C2000 / UNS N06200 Nickel Alloy Seamless Pipe MT23

Executive standard

Form	ASTM
Plate, sheet, and strip	ASTM B 575
Seamless pipe and tube	ASTM B622
Bar	ASTM B574
Welded pipe and tube	ASTM B619
Forging	ASTM B564

%	Ni	Cr	Mo	Fe	Co	C	Mn	Si	P
min	balance	22.0	15.0
max	balance	24.0	17.0	3.0	2.0	0.010	0.50	0.08	0.025

Physical properties

Product name	ALLOY C-2000
	UNS N06200
	NICR23M016CU
Density	8.9 g/cm3
Melting range	1335-1380℃

The minimum value of the mechanical properties of an alloy at room temperature

Alloys and states	Tensile strength	Yield strength	Extend rate
Alloys and states	RM N/MM2	RP0.2N/MM2	A5%
Alloy C-2000	690	283	45

Product features

Alloy C2000 this alloy is designed to resist more corrosive chemicals, including sulfuric acid, hydrochloric acid, chlorofluoroic acid. Different from the previous optimized NI-CR-MO alloy, which can only resist oxidizing or reducing acids, C-2000 alloy has corrosion resistance in both environments. The combined action of molybdenum and copper (at 16% and 1.6% respectively) makes the alloy have excellent corrosion resistance in reducing medium, and the high chromium content (23% wt) ensures the corrosion resistance in oxidizing medium.

1. It is not appropriate for NI-CR-MO alloy to undergo post weld stress relief treatment at about 650 ℃. Generally, post weld heat treatment is not required, but if stress relief is required, complete solution annealing at 1149 ℃ is recommended, followed by water treatment. 2.The hot working temperature of the alloy ranges from 1080 ℃ to 900 ℃, and the cooling method is water or other rapid cooling methods. In order to ensure the best corrosion resistance, solution heat treatment should be carried out after hot working.

Metallographic structure

Alloy C-22 has a face centered cubic crystal structure Alloy C2000 alloy has a face-centered cubic lattice structure, and its chemical composition ensures metallographic stability and anti-sensitization.

Corrosion resistance

Alloy C2000 is designed to resist more corrosive chemicals, including sulfuric acid, hydrochloric acid, and hydrofluoric acid. Different from the previous optimized Ni-Cr-Mo alloy, which can only resist oxidizing or reducing acids, C-2000 alloy has corrosion resistance in both environments.

The combined action of Mo and Cu (at 16% and 1.6% levels respectively) makes the alloy have excellent corrosion resistance in reducing medium, and the high chromium content (23% wt) ensures the corrosion resistance in the oxidizing medium.

Scope of application

Allow C2000 offers great potential to increase production. When used in the original Ni-Cr-Mo alloy, its enhanced corrosion resistance can obtain longer equipment life under the same material thickness and higher safety factor under worse conditions. With the improvement of corrosion resistance in all aspects, the equipment can be used for many purposes (reactor, heat exchanger, valve, pump, etc.), so as to receive greater return on investment. For example, a reactor can adapt to hydrochloric acid mixture, and then change into nitric acid based mixture. C-2000 is the best nickel based alloy material that can adapt to various processes because of its unique ability.

Other applications

1. Acetic acid / acetic anhydride 2. Acid leaching 3. Cellophane manufacturing 4. Chlorination system 5. Complex mixed acids 6. Roller of galvanizing bath 7. Expansion bellows

8. Flue gas scrubber system 9. Geothermal well 10. Incineration washer system 11. Nuclear fuel regeneration 12. Pesticide production 13. Phosphoric acid production 14. Pickling system

15. Plate heat exchanger 16. Filtration system 17. Sulfur dioxide cooling tower 18. Sulfonation system 19. Tubular heat exchanger 20. Surfacing valve 21. Hydrogen fluoride furnace cleaning
